PRESTO is a large suite of
pulsar search and analysis software developed by Scott Ransom mostly
from scratch. It was primarily designed to efficiently search for
binary millisecond pulsars from long observations of globular clusters
(although it has since been used in several surveys with short
integrations and to process a lot of X-ray data as well). It is
written primarily in ANSI C, with many of the recent routines in Python. According to Steve Eikenberry, PRESTO
stands for: PulsaR Exploration
To date, PRESTO has
discovered over 300 pulsars,
including more than 150 recycled
pulsars, most of which are in binaries!
New in version 2:
- WAPP, BCPM, Spigot, and 1-bit analog filterbank data are deprecated!
- Dramatically improved internal handling (giving better dynamic
range and RFI removal) of PSRFITS and SIGPROC filterbank data
- Massive speed-ups (factors of 2 or more) of accelsearch when
all of the F-Fdot plane can fit into core memory (that can be set
by changing values in
- Many bug fixes and several new scripts (including new orbit fitters)
Written with portability, ease-of-use, and memory efficiency in mind, it can currently handle raw data
from the following pulsar machines or formats:
Notice that the following formats which used to be supported are not:
search-format data (as from GUPPI at
the GBT, PUPPI and the Mock Spectrometers at Arecibo, and much new and archived data from Parkes)
- 1-, 2-, 4-, 8-, and 32-bit (i.e. float) filterbank format
- A time series
composed of single precision (i.e. 4-byte) floating point data
- Photon arrival times (or
events) in ASCII or double-precision binary formats
- Wideband Arecibo
Pulsar Processor (WAPP) at Arecibo
- The Parkes and Jodrell
Bank 1-bit filterbank formats
at the GBT (may it RIP...)
- Berkeley-Caltech Pulsar
Machine (BCPM) at the GBT (may it RIP...)
If you need to process them, you can either checkout the "classic"
branch of PRESTO (see below), which is not being actively developed.
Or you can use DSPSR
The software is composed of numerous
routines designed to handle three main areas of pulsar analysis:
to convert those formats into SIGPROC
filterbank format (and/or maybe someday soon, PSRFITS search format).
You can grab DSPSR here. If you
really need to get one of these machines working in PRESTO v2, let
me know and we can probably make it happen. It will take a day or two
of porting for each backend.
Many additional utilities are
provided for various tasks that are often required when working with
pulsar data such as time conversions, Fourier transforms, time series and
FFT exploration, byte-swapping, etc.
detection (rfifind) and removal (zapbirds) ,
de-dispersion (prepdata, prepsubband, and mpiprepsubband),
barycentering (via TEMPO).
- Searching: Fourier-domain
acceleration (accelsearch), single-pulse (single_pulse_search.py), and
phase-modulation or sideband searches (search_bin).
- Folding: Candidate
optimization (prepfold) and Time-of-Arrival (TOA) generation (get_TOAs.py).
- Misc: Data exploration (readfile,
exploredat, explorefft), de-dispersion planning (DDplan.py), date
conversion (mjd2cal, cal2mjd), tons of python pulsar/astro libraries,
average pulse creation, flux density estimation, and more...
The Fourier-Domain acceleration search technique that PRESTO uses in
described in Ransom,
Middleditch (2002), and the phase-modulation search
technique used by
is described in Ransom,
Eikenberry (2003). Some other basic information
about PRESTO can be found in my thesis.
eventually get around to finishing the documentation for PRESTO,
but until then you should know that each routine returns its basic
usage when you call it with no arguments. I am also willing to
provide limited support via email or telephone (434-296-0320).
The PRESTO source
code is released under the GPL and can be browsed
or gotten from here
in many different
ways (including zipped or tar'd or via git).
you are too lazy to read how to get it but have git on your system
> git clone git://github.com/scottransom/presto.git
To update it on a regular basis
> cd $PRESTO
> git pull
and then re-make things in $PRESTO/src.
For more detailed installation instructions, see INSTALL.
If you don't want to mess with git (which means that you will need to
re-install a tarball whenever there are updates) you can get it from the "Download Source" link on the github page.
If you want the "classic" branch, do the following:
git clone git://github.com/scottransom/presto.git
> cd presto
git remote add classic origin/classic
> git checkout -b classic origin/classic
then build as per the (old) INSTALL file.
If you plan to tweak the code, I highly suggest that you use git and
clone the directory (or fork it using an account on github). If you plan on doing any
significant development, please let me know and I'll either add you as
a developer, or we can push/pull changes via git/github. Code
contributions and/or patches to fix bugs are most welcome!
barycentering data, PRESTO uses TEMPO. You should get the newest version from Sourceforge.
You will also need FFTW,
CFITSIO, and PGPLOT.
There is now a tutorial
available that will show you the basics. It is included in the
docs directory of the source code as well.
Other Languages: Here is a Romanian translation of this page (thanks to Alexsandra Seremina!) Let me know if you have others!
Thoughts: Please let me know if you decide to use PRESTO
for any "real"
searches. And if you find anything with it, it would be great if
you would cite either my thesis or whichever of the two papers listed
above is appropriate. Thanks!
thanks go to Steve Eikenberry for his help developing the
algorithms, Dunc Lorimer for the basic code which is used to
process BCPM and WAPP data, David Kaplan for lots of help with the
GBT SPIGOT code, Jason Hessels for many contributions to the
Python routines (and along with Maggie Livingstone for the
rednoise reduction routine), Anne Archibald (for significant help with
the recent accelsearch improvements), and Paul Demorest, Paul Ray,
Paul Scholz, Ingrid Stairs, Fernando
Camilo, Cees Bassa, Patrick Lazarus, Mike Keith, Kevin Stovall, and Paulo Freire for
comments and suggestions (and even some patches!).
