./toolbox/io
io_sdfits__define.pro

IO
|
+-io_sdfits

All known superclasses:

IO

Last modification date:

Thu Jun 2 23:56:08 2005

IO_SDFITS is the base class for spectral line and continuum sdfits classes. All the general functionality for reading, writing, navigating sdfits files, and for; translating their info to data containers is placed in this class. See UML for all IO Classes, or IO_SDFITS UML for just the line and continuum sdfits classes.

Routine Summary  30 routines

procedure io_sdfits__define
IO_SDFITS is the base class for spectral line and continuum sdfits classes.

procedure IO_SDFITS::set_debug_on
The class can be made to verbosly describe what its doing

procedure IO_SDFITS::set_debug_off
The class can be made to be quite

procedure IO_SDFITS::set_project, dir, _EXTRA=_EXTRA
This method looks into the given directory and attempts to load any existing index file.

procedure IO_SDFITS::set_file, file_name, file_path=string, index_name=string, online=online, _EXTRA=_EXTRA
This method can be used to lock the io object into working with only one sdfits file.

procedure IO_SDFITS::add_file, file_name, /new_index, index_name=index_name
This method is the main interface to the sdfits io classes.

procedure IO_SDFITS::load_index, file_name, file_path=string
This method will read an index file, check that the index agrees with the sdfits files on disk, and create fits objects for the files listed in its index.

procedure IO_SDFITS::set_file_path, file_path
Sets the path where index file and all sdfits files are to be found

function IO_SDFITS::get_file_path()
Gets the path where index file and all sdfits files are to be found

function IO_SDFITS::is_data_loaded()
Checks to see if this object has any sdfits files connected to it.

procedure IO_SDFITS::set_index_file_name, file_name
Sets the file name of the index file.

function IO_SDFITS::get_index_file_name([/full])
Retrieves the file name of the index file.

procedure IO_SDFITS::list[, start][, finish], [sortcol=string], _EXTRA=_EXTRA, /verbose, [/user], [columns=string array]
Prints out rows from the index file used by object.

function IO_SDFITS::get_index(_EXTRA=_EXTRA)
Returns indicies of rows in index file that match search.

function IO_SDFITS::get_scan_info(scan_number)
Returns a structure that contains info about the scan number given, such as scan number, procedure name, number of integrations, ifs, etc.

procedure IO_SDFITS::list_index_header
Prints out the header section of the index file used by this object

function IO_SDFITS::get_index_values(column_name, _EXTRA=_EXTRA)
Returns the values contained in the index file column used by this object

function IO_SDFITS::get_index_files(_EXTRA=_EXTRA, full=full)
Returns the unique file names (no path) contained in the index file used by this object

function IO_SDFITS::get_index_projects(_EXTRA=_EXTRA)
Returns the unique project names (no path) contained in the index file used by this object

function IO_SDFITS::get_index_sources(_EXTRA=_EXTRA)
Returns the unique source names (no path) contained in the index file used by this object

function IO_SDFITS::get_index_procedures(_EXTRA=_EXTRA)
Returns the unique procedure names (no path) contained in the index file used by this object

function IO_SDFITS::get_index_scans(_EXTRA=_EXTRA)
Returns the unique scan names (no path) contained in the index file used by this object

function IO_SDFITS::are_index_file_indicies_unique()
Diagnostic function to determine if index file indicies are unique (as they should be)

procedure IO_SDFITS::set_more_format_on
Sets the object to print rows using the interactive 'more' format

procedure IO_SDFITS::set_more_format_off
Sets the object NOT to print rows using the interactive 'more' format

procedure IO_SDFITS::list_available_columns
Prints the available columns from the rows section for list; these are also the valid search keywords

procedure IO_SDFITS::set_user_columns, columns
Sets what columns should be used for user listing

procedure IO_SDFITS::list_user_columns
Prints the columns currently selected for the user specified listing

function IO_SDFITS::get_num_index_rows()
Retrieves number of records the object is connected to - or how many rows currently in the index file

function IO_SDFITS::sort_search_results(results, column)
Given an integer array representing some rows in the index, sorts this array by a given column name in the index file

Routine Details

io_sdfits__define

procedure io_sdfits__define

IO_SDFITS is the base class for spectral line and continuum sdfits classes. All the GENERAL functionality for reading, writing, navigating sdfits files, and for; translating their info to data containers is placed in this class. See UML for all IO Classes, or IO_SDFITS UML for just the line and continuum sdfits classes.

Inherits

io

Version

$Id: io_sdfits__define.pro,v 1.49 2005/06/02 17:10:43 bgarwood Exp $

IO_SDFITS::set_debug_on

procedure IO_SDFITS::set_debug_on

The class can be made to verbosly describe what its doing

IO_SDFITS::set_debug_off

procedure IO_SDFITS::set_debug_off

The class can be made to be quite

IO_SDFITS::set_project

procedure IO_SDFITS::set_project, dir, _EXTRA=_EXTRA

This method looks into the given directory and attempts to load any existing index file. If the file does not exist, all sdfits files in this directory are loaded using the add_file method, and a new index is created. For a complete description, see the flowchart.

Examples

    path = '/users/me/my_project'
    io = obj_new('io_sdfits_line')
    io->set_project, path


Uses

add_file

Parameters
dir in string	The path in which all sdfits files and possibly the index file are to be found

Keywords
_EXTRA	.

IO_SDFITS::set_file

procedure IO_SDFITS::set_file, file_name, file_path=string, index_name=string, online=online, _EXTRA=_EXTRA

This method can be used to lock the io object into working with only one sdfits file. An index file is automatically created (overwrites pre-existing one).

Examples

   io = obj_new('io_sdfits_cntm')
   io->set_file, 'TREG_04_01.dcr.raw.fits'


Uses

add_file

Parameters
file_name in string	The file name of the sdfits file (no path)

Keywords
file_path in string	Where to find the sdfits file
index_name in string (def. 'file_name.index')	What to call the new index file
online	.
_EXTRA	.

IO_SDFITS::add_file

procedure IO_SDFITS::add_file, file_name, /new_index, index_name=index_name

This method is the main interface to the sdfits io classes. It is used in turn by set_project and set_file. Most of the logic for keeping the index file in sync with the fits files is coded in this method. For a complete description, see the flowchart.

Examples

    path = '/users/me/my_project'
    io = obj_new('io_sdfits_line')
    io->set_file_path, path
    io->add_file, 'TREG_O1_04.acs.raw.fits'


Parameters
file_name in string	Name of sdfits file to add (no path)

Keywords
new_index in boolean (def. 0)	Forces the creation of a new index file (overwrites pre-existing index)
index_name	.

IO_SDFITS::load_index

procedure IO_SDFITS::load_index, file_name, file_path=string

This method will read an index file, check that the index agrees with the sdfits files on disk, and create fits objects for the files listed in its index.

Examples

    path = '/users/me/my_project'
    io = obj_new('io_sdfits_line')
    io->load_index, 'my_index', file_path='/users/me/my_project'


IO_SDFITS::set_file_path

procedure IO_SDFITS::set_file_path, file_path

Sets the path where index file and all sdfits files are to be found

Examples

    path = '/users/me/my_project'
    io = obj_new('io_sdfits_line')
    io->set_file_path, path


IO_SDFITS::get_file_path

function IO_SDFITS::get_file_path()

Gets the path where index file and all sdfits files are to be found

Returns

{type=string} Path where index file and all sdfits files are to be found.

Examples

    path = '/users/me/my_project'
    io = obj_new('io_sdfits_line')
    io->set_project, path
    print, io->get_file_path()
    '/users/me/my_project'


IO_SDFITS::is_data_loaded

function IO_SDFITS::is_data_loaded()

Checks to see if this object has any sdfits files connected to it.

Returns

0 - data is not loaded; 1 - data is loaded.

IO_SDFITS::set_index_file_name

procedure IO_SDFITS::set_index_file_name, file_name

Sets the file name of the index file.

Parameters
file_name	.

IO_SDFITS::get_index_file_name

function IO_SDFITS::get_index_file_name([/full])

Retrieves the file name of the index file.

Returns

The file name of the index file

IO_SDFITS::list

procedure IO_SDFITS::list[, start][, finish], [sortcol=string], _EXTRA=_EXTRA, /verbose, [/user], [columns=string array]

Prints out rows from the index file used by object. For exact search parameters to enter, see LINE_INDEX::search_index or CNTM_INDEX::search_index

Parameters
start in, optional long	where to start the range to list
finish in, optional long	where to stop the range to list

Keywords
sortcol in, optional string	what index column name to order listwith
_EXTRA	.
verbose in boolean (def. 0)	Print out ALL information?
user in, optional boolean	print out columns specified using set_user_columns? Takes precedence over verbose keyword
columns in, optional string array	array of column names to print out upon list command. Takes precedence over user and verbose keywords.

IO_SDFITS::get_index

function IO_SDFITS::get_index(_EXTRA=_EXTRA)

Returns indicies of rows in index file that match search. For exact search parameters to enter, see LINE_INDEX::search_index or CNTM_INDEX::search_index

Returns

Long array of indicies of rows in index file that match search

Uses

INDEX_FILE::search_index

Keywords
_EXTRA	.

IO_SDFITS::get_scan_info

function IO_SDFITS::get_scan_info(scan_number)

Returns a structure that contains info about the scan number given, such as scan number, procedure name, number of integrations, ifs, etc..

Returns

Structure containing info on scan

Uses

INDEX_FILE::get_scan_info

IO_SDFITS::list_index_header

procedure IO_SDFITS::list_index_header

Prints out the header section of the index file used by this object

Uses

INDEX_FILE::list_header

IO_SDFITS::get_index_values

function IO_SDFITS::get_index_values(column_name, _EXTRA=_EXTRA)

Returns the values contained in the index file column used by this object

Returns

the values found in the index column name specified.

Uses

INDEX_FILE::get_column_values

IO_SDFITS::get_index_files

function IO_SDFITS::get_index_files(_EXTRA=_EXTRA, full=full)

Returns the unique file names (no path) contained in the index file used by this object

Returns

The unique file names (no path) contained in the index file used by this object

Uses

INDEX_FILE::get_column_values

IO_SDFITS::get_index_projects

function IO_SDFITS::get_index_projects(_EXTRA=_EXTRA)

Returns the unique project names (no path) contained in the index file used by this object

Returns

The unique project names (no path) contained in the index file used by this object

Uses

INDEX_FILE::get_column_values

IO_SDFITS::get_index_sources

function IO_SDFITS::get_index_sources(_EXTRA=_EXTRA)

Returns the unique source names (no path) contained in the index file used by this object

Returns

The unique source names (no path) contained in the index file used by this object

Uses

INDEX_FILE::get_column_values

IO_SDFITS::get_index_procedures

function IO_SDFITS::get_index_procedures(_EXTRA=_EXTRA)

Returns the unique procedure names (no path) contained in the index file used by this object

Returns

The unique procedure names (no path) contained in the index file used by this object

Uses

INDEX_FILE::get_column_values

IO_SDFITS::get_index_scans

function IO_SDFITS::get_index_scans(_EXTRA=_EXTRA)

Returns the unique scan names (no path) contained in the index file used by this object

Returns

The unique scan names (no path) contained in the index file used by this object

Uses

INDEX_FILE::get_column_values

IO_SDFITS::are_index_file_indicies_unique

function IO_SDFITS::are_index_file_indicies_unique()

Diagnostic function to determine if index file indicies are unique (as they should be)

Returns

0 - bad, 1 - good

IO_SDFITS::set_more_format_on

procedure IO_SDFITS::set_more_format_on

Sets the object to print rows using the interactive 'more' format

IO_SDFITS::set_more_format_off

procedure IO_SDFITS::set_more_format_off

Sets the object NOT to print rows using the interactive 'more' format

IO_SDFITS::list_available_columns

procedure IO_SDFITS::list_available_columns

Prints the available columns from the rows section for list; these are also the valid search keywords

IO_SDFITS::set_user_columns

procedure IO_SDFITS::set_user_columns, columns

Sets what columns should be used for user listing

Parameters
columns in, required string array	array of columns to print on list command

IO_SDFITS::list_user_columns

procedure IO_SDFITS::list_user_columns

Prints the columns currently selected for the user specified listing

IO_SDFITS::get_num_index_rows

function IO_SDFITS::get_num_index_rows()

Retrieves number of records the object is connected to - or how many rows currently in the index file

Returns

number of records this object is connected to

IO_SDFITS::sort_search_results

function IO_SDFITS::sort_search_results(results, column)

Given an integer array representing some rows in the index, sorts this array by a given column name in the index file

Parameters
results in, required array	integer array representing some rows in the index file
column in, required string	must be uniquely identify a column in the index file
